Model |
Q1516 |
QL1518 |
QL1530 |
QL1537 |
QL1545 |
|
Load Capacity (Kg) |
1500 |
||||
|
Safe capacity, fully extended (Kg) |
1300 |
1300 |
1100 |
1000 |
700 |
|
Lift Height (mm) |
1600 |
1800 |
3000 |
3700 |
4500 |
|
Load Center (mm) |
500 |
||||
|
Fork length (mm) |
950/1150 |
||||
|
Fork Width, outside (mm) |
200-700 |
||||
|
Min. Height of Fork (mm) |
50 |
||||
|
Leg Length (mm) |
875 |
||||
|
Leg Width, outside (mm) |
490/615 |
||||
|
Turning Radius (mm) |
1670 |
||||
|
Front Wheel |
Φ210×70、2 |
||||
|
Rear Wheel |
φ230×82、1 |
||||
|
Overall Length (mm) |
2252/2652/2806 |
||||
|
Overall Width (mm) |
1042 |
||||
|
Mast Height, extended |
2355mm |
2790mm |
4040mm |
4700mm |
5500mm |
|
Mast Height, lowered |
2155mm |
2355mm |
2121mm |
1830mm |
2080mm |
|
Reach distance |
500mm |
||||
|
Controller |
24V/200A |
||||
|
Battery |
24v/270Ah |
24v/400Ah |
|||
|
Net Weight (Kg) |
1745 |
1750 |
1840 |
2070 |
2110 |
