Model |
CL1016 |
CL1026 |
CL1032 |
CL1036 |
CL1516 |
CL1526 |
CL1532 |
CL1536 |
CL1546 |
|
Load Capacity (Kg) |
1000 |
1500 |
|||||||
|
Safe capacity, fully extended (Kg) |
1000 |
800 |
700 |
600 |
1500 |
1200 |
1100 |
900 |
800 |
|
Lift Height (mm) |
1600 |
2600 |
3200 |
3600 |
1600 |
2600 |
3200 |
3600 |
4600 |
|
Load Center (mm) |
600 |
||||||||
|
Fork length (mm) |
1150 |
||||||||
|
Fork Width, outside (mm) |
570/695 |
||||||||
|
Min. Height of Fork (mm) |
86 |
||||||||
|
Leg Length (mm) |
875 |
||||||||
|
Leg Width, outside (mm) |
490/615 |
||||||||
|
Turning Radius (mm) |
1460 |
1605 |
|||||||
|
Front Wheel |
φ80×70、4 |
||||||||
|
Rear Wheel |
φ250×78、1 |
||||||||
|
Overall Length (mm) |
1893 |
||||||||
|
Overall Width (mm) |
805 |
||||||||
|
Mast Height, extended (mm) |
2077 |
3137 |
3687 |
4087 |
2077 |
3137 |
3687 |
4087 |
5100 |
|
Mast Height, lowered (mm) |
2077 |
1877 |
2127 |
2327 |
2077 |
1877 |
2127 |
2327 |
2098 |
|
Battery |
24/210 |
||||||||
|
Controller |
USA CURTIS (AC Power) |
||||||||
|
Charger Voltage |
According to customers' need |
||||||||
|
Running Hour (h) |
5 |
||||||||
|
Net Weight (Kg) |
680 |
860 |
890 |
920 |
710 |
890 |
920 |
950 |
1365 |
